Datalogic Gryphon 4500 Barcode Scanners
Premium 1D and 2D handheld barcode scanners for retail, healthcare, manufacturing, commercial services and general business applications.
The Datalogic Gryphon 4500 Series combines a megapixel area imager, 1D/2D barcode capture, ergonomic handheld design and Datalogic Green Spot good-read feedback with corded and cordless configurations.
Choose the GD4500 for corded scanning, the GBT4500 for Bluetooth cordless operation, or the GM4500 for Datalogic STAR cordless radio.
Standard-range, high-density and specialist healthcare configurations are available, so the exact manufacturer part number matters.
Datalogic Gryphon 4500 at a Glance
1D & 2D Scanning
Capture common linear and two-dimensional barcode symbologies with a high-performance area imager.
Megapixel Sensor
Datalogic's megapixel imaging platform provides strong barcode-reading performance and image capture capability.
Corded or Cordless
Choose GD4500 corded, GBT4500 Bluetooth or GM4500 STAR cordless configurations.
Wireless Charging
Cordless Gryphon 4500 models use contactless inductive charging rather than conventional exposed charging contacts.
Green Spot
Datalogic Green Spot technology provides clear good-read feedback directly on the scanned barcode.
Warm White Illumination
Designed to provide comfortable illumination while supporting barcode reading across different label colours.
IP52
The Gryphon 4500 enclosure is rated IP52 for professional everyday environments.
1.8m Drop Rating
Datalogic specifies resistance to repeated drops from 1.8 metres onto concrete.
Which Gryphon 4500 Do You Need?
Start with the way the scanner will connect to the workstation or business system.
Datalogic GD4500
Corded Gryphon 4500.
Best for fixed workstations where the scanner remains close to the till, desk, counter or workstation.
Typical applications: retail checkout, pharmacy, reception, office and fixed scanning stations.
Datalogic GBT4500
Bluetooth cordless Gryphon 4500.
Provides freedom from the workstation cable while retaining the premium Gryphon scanning platform.
Typical applications: retail, stockrooms, healthcare, light manufacturing and mobile workstation scanning.
Datalogic GM4500
STAR Cordless System Gryphon 4500.
Uses Datalogic's dedicated narrow-band STAR radio rather than Bluetooth.
Typical applications: professional cordless installations where a dedicated Datalogic radio link is preferred.
GD4500 vs GBT4500 vs GM4500
| Feature | GD4500 | GBT4500 | GM4500 |
|---|---|---|---|
| Connection | Corded | Bluetooth | Datalogic STAR radio |
| 1D / 2D | Yes | Yes | Yes |
| Megapixel Imager | Yes | Yes | Yes |
| Cordless Operation | No | Yes | Yes |
| Wireless Charging | Not required | Available | Available |
| Wireless Range | Not applicable | Up to approximately 100m* | Up to approximately 50m* |
| Typical Use | Fixed workstation | Flexible cordless scanning | Dedicated cordless installation |
*Maximum manufacturer figures. Practical wireless range depends on the environment, interference, configuration and installation.
Premium 1D & 2D Barcode Scanning
The Gryphon 4500 is designed as a premium general-purpose scanner rather than a basic entry-level barcode reader.
1D Barcodes
Read common linear barcodes used across retail, inventory, healthcare and business applications.
2D Barcodes
Capture QR Code, Data Matrix and other supported two-dimensional symbols.
Mobile Screens
Suitable configurations can read barcodes presented on smartphones and other electronic displays.
Specialist Codes
The family supports additional barcode types including stacked, postal, DotCode and selected Digimarc configurations.
4-Dot Aiming & Datalogic Green Spot
Scanning feedback matters when operators are processing large numbers of barcodes throughout a working day.
4-Dot Aiming Pattern
The Gryphon 4500 uses a four-dot aiming pattern with a central cross to help the operator identify the active reading area.
This can be particularly useful where several barcodes are positioned close together and the operator needs to select a specific code.
Green Spot Good-Read Feedback
Datalogic's Green Spot projects visual confirmation directly onto the barcode after a successful scan.
This gives the operator another form of confirmation alongside conventional audible and visual scanner feedback.
Standard Range or High Density?
Not every Gryphon 4500 has identical optics. Choose the scanner around the barcodes you actually need to capture.
Standard Range
Best for general-purpose barcode scanning.
Suitable for many retail, stock, commercial, pharmacy and general business applications using conventional barcode sizes.
For example, Datalogic specifies standard-range reading of a 13 mil EAN/UPC barcode out to approximately 71cm under test conditions.
High Density
Best for smaller and denser barcodes.
Consider HD configurations where the application uses particularly small labels or high-density symbols.
Datalogic's HD specifications include support for very fine Code 39 and PDF417 symbols.
Test the actual barcode where possible. Reading distance depends on barcode size, density, symbology, print quality, contrast and the exact Gryphon configuration.
Gryphon 4500 Cordless Scanning
Bluetooth
GBT4500 models use Bluetooth for flexible cordless scanning.
STAR Cordless
GM4500 models use Datalogic's dedicated STAR Cordless System radio technology.
Wireless Charging
Contactless inductive charging removes conventional exposed battery-charging contacts from the charging process.
Cradle Operation
The adjustable cradle can support charging and presentation-style hands-free scanning.
Designed for Busy Cordless Workflows
Datalogic specifies a 3250mAh lithium-ion battery for the cordless Gryphon 4500 models and more than 80,000 reads between charges under its stated test conditions.
High-Capacity Battery
Designed to support demanding business scanning workloads across operational shifts.
Contactless Charging
Inductive charging avoids exposed charging contacts that may otherwise require cleaning or maintenance.
Scan While Charging
Suitable cordless configurations can continue scanning while positioned in the compatible charging base.
Datalogic Gryphon 4500 for Retail
Checkout
Use the GD4500 as a premium handheld scanner at fixed checkout and service positions.
Mobile Coupons
Capture supported QR and 2D codes displayed on customer smartphones.
Loyalty
Scan suitable physical and digital loyalty identifiers.
Stockroom
Cordless GBT4500 and GM4500 configurations provide greater freedom around stock and service areas.
Gryphon 4500 Healthcare Models
Datalogic produces dedicated healthcare configurations of the Gryphon 4500 with disinfectant-ready and antimicrobial enclosures for clinical applications.
Patient Identification
Capture supported patient wristband barcodes within appropriate healthcare workflows.
Medication
Read suitable medication and patient identifiers within the organisation's chosen workflow.
Laboratory
Use suitable configurations for specimen and laboratory barcode capture.
Healthcare Housing
Healthcare variants are designed around the cleaning requirements of clinical environments.
Choose the healthcare MPN where clinical cleaning requirements apply. Do not assume the standard black or white Gryphon enclosure has the same healthcare-specific characteristics.
Gryphon 4500 for Manufacturing & Commercial Applications
Components
Capture suitable component and product identification barcodes.
Work in Progress
Scan WIP, batch and production identifiers in suitable indoor environments.
Quality Control
Use barcode capture within inspection, verification and quality workflows.
General Business
Suitable for commercial services, offices, counters and professional data-capture applications.
Need a scanner for harsh industrial environments? The Gryphon 4500 is a premium general-purpose scanner. For demanding factory floors, loading bays or outdoor industrial work, compare ultra-rugged scanner families instead.
Professional Durability Without an Industrial Form Factor
The Gryphon 4500 provides significantly more physical protection than a basic office scanner while retaining a compact general-purpose handheld design.
IP52
Protection suitable for professional indoor scanning environments.
1.8m Drops
Datalogic specifies resistance to repeated 1.8m drops onto concrete.
10 Million Trigger Actuations
The trigger is designed around high-frequency professional scanning workloads.
Ergonomic Design
A balanced handheld form is intended to reduce operator fatigue during repeated use.
Handheld or Presentation Scanning
Handheld
Pick up the Gryphon and aim directly at the barcode for conventional trigger-operated scanning.
Suitable where products, documents or barcodes vary in size, position or orientation.
Presentation Mode
Compatible stands and cordless cradles can position the scanner for hands-free presentation scanning.
This can work well at counters and workstations where items are brought to the scanner.
Example Gryphon 4500 Configurations
Datalogic offers a substantial number of Gryphon 4500 configurations. These examples show why the complete MPN matters.
GBT4500-BK-WLC
Bluetooth 2D megapixel imager, black, with wireless charging capability.
GBT4500-BK-HD-WLC
Bluetooth 2D megapixel imager with high-density optics and wireless charging.
GBT4500-HC-WLC
Bluetooth healthcare Gryphon 4500 with wireless charging capability.
GBT4500-BK-BTK1
Black Bluetooth USB kit including scanner, compatible base and USB cable.
GM4500-BK-433-WLC
Black GM4500 using Datalogic STAR 433MHz cordless technology.
GM4500-HC-433-WLC
Healthcare GM4500 using Datalogic STAR cordless technology.
Availability varies by configuration and region. Use the exact manufacturer part number when comparing suppliers or requesting a quote.
How to Choose a Datalogic Gryphon 4500
1. Corded or Cordless?
Choose GD4500 for corded operation or GBT/GM for cordless scanning.
2. Bluetooth or STAR?
For cordless deployments, decide whether Bluetooth or Datalogic STAR radio better suits the installation.
3. Standard or HD?
Match the scanner optics to the size and density of the barcodes being captured.
4. Healthcare?
Select a healthcare configuration where clinical cleaning requirements apply.
5. Handheld or Hands-Free?
Consider the appropriate stand or cradle where presentation scanning is required.
6. Which Interface?
Confirm the scanner or kit supports the required workstation connection.
7. Scanner or Kit?
Check whether the MPN includes the required cradle, cable and other components.
8. Exact MPN?
Use the complete Datalogic part number when comparing prices.
Why the Exact Gryphon 4500 MPN Matters
A listing described simply as a “Datalogic Gryphon 4500” does not tell you enough to know what you are buying.
Connection
The scanner may be corded, Bluetooth or Datalogic STAR cordless.
Optics
Standard-range and high-density configurations are available.
Housing
Standard and healthcare-specific configurations have different intended applications.
Kit Contents
Some MPNs are scanner-only while others include a base, cable or other components.
If you already know the Datalogic MPN you need, send the part number and quantity and we'll price the exact configuration.
Gryphon 4500 or Another Scanner?
Gryphon 4500
Premium general-purpose scanning.
Ideal where scanning performance, ergonomics and professional features matter but an ultra-rugged industrial scanner is unnecessary.
Presentation Scanner
High-volume fixed counter scanning.
Consider a dedicated presentation scanner where most items are passed in front of a permanently mounted reader.
Zebra DS9308 →Ultra-Rugged Scanner
Warehouse and industrial scanning.
Consider an ultra-rugged scanner for harsh environments, loading bays, demanding manufacturing or repeated heavy-duty handling.
Zebra DS3608 →Datalogic Gryphon 4500 FAQs
Does the Gryphon 4500 scan 2D barcodes?
Yes. The Gryphon 4500 is a 2D area-imaging family supporting common 1D and 2D barcode types plus additional supported symbologies.
What is the difference between GD4500 and GBT4500?
GD4500 is the corded Gryphon 4500. GBT4500 is the Bluetooth cordless version.
What is the GM4500?
GM4500 is the cordless Gryphon 4500 using Datalogic's STAR Cordless System rather than Bluetooth.
Can Gryphon 4500 scan QR codes?
Yes. Suitable Gryphon 4500 configurations support QR Code and other common 2D symbologies.
Can it scan barcodes from phones?
Yes. The area-imaging platform is designed to read suitable barcodes displayed on smartphones and other electronic screens.
Does the cordless Gryphon use wireless charging?
Yes. GBT4500 and GM4500 configurations are available with Datalogic's contactless inductive charging system.
Is there a healthcare Gryphon 4500?
Yes. Datalogic offers healthcare models with disinfectant-ready and antimicrobial enclosures.
Can Tek Direkt quote a specific Gryphon 4500?
Yes. Send the complete Datalogic manufacturer part number and quantity so the exact configuration can be priced.
Need Datalogic Gryphon 4500 Barcode Scanners?
Tell us whether you need corded or cordless scanning, standard or high-density optics, the type of barcodes you're scanning and whether healthcare housing is required.
If you've already selected the hardware, send the Datalogic MPN + quantity and we'll price the exact configuration.
Already have another supplier quote? Send the same MPNs and quantities and we'll give you another price to compare.
No calls. No meetings. No messing about. Just straightforward hardware and a price.
